ZHIYI Utilizing the latest WiFi 6 (AX3000) technology, the XGPON ONU 10G PON DUAL BAND AX3000 ZY-XG-304AX is equipped with advanced ITU-T G.987 (XG-PON), and ITU-T G.9807.1 (XGS-PON) PON interfaces, as well as IEEE 802.11ax (WiFi 6) interfaces. This allows Internet Service Providers to deliver internet speeds exceeding 2.5Gbps, surpassing the limitations of GPON technology.

The ZY-XG-304AX features built-in Ethernet LAN ports, including one 2.5GE BASE-T port and 3 PCS of 1GE BASE-T ports, enabling ultrafast device connections. Its WLAN interface supports MU-MIMO OFDMA technology with 2x2 2.4GHz MIMO and 5GHz MIMO Wi-Fi antennas, providing enhanced performance for a variety of internet applications such as video streaming, web browsing, online gaming, and file transfers.

XGPON ONUs (Optical Network Units) 10G PON DUAL BAND AX3000 ZY-XG-304AX-x26 play a crucial role in the advancement of fiber access networks. Compliant with ITU-T G.987 (XGPON) and G.9807 (XGS-PON) standards, these devices offer symmetrical speeds of up to 10 Gbps, providing residential and business users with the necessary bandwidth for high-quality video streaming, cloud services, and extensive IoT applications. Their primary function is to efficiently terminate the optical line, converting signals for end-user devices while ensuring quality of service, security, and network reliability.

Our XGPON ONUs are fully compatible with our ZY-XG(S)0810G OLT, making them the ideal choice for your optical communication network.

ITEM	ZY-XG-304AX-X26
ITEM	ZY-XG-304AX-X26
PON interface	●10G PON port: Class B+ ●SC single mode, SC/UPC connector ●TX optical power: 6dBm (XGS-PON), 5dBm (XG-PON) ●RX sensitivity: -28dBm ●Overload optical power: -8dBm ●Transmission distance: 20km ●Wavelength: XG(S)-PON:DS 1577nm/US 1270nm
User interface	●12.5GE, Auto-negotiation, RJ45 ports ●3GE, Auto-negotiation, RJ45 ports ●1*USB 3.0
O&M	● WEB/TELNET/OAM/OMCI/TR069 ● Support private OAM/OMCI protocol
Internet connection	Support Bridge/Router mode
VoIP	● SIP and IMS SIP ● G.711a/G.711u/G.722/G.729 Codec ● Echo cancellation,VAD/CNG,DTMF Relay ● T.30/T.38 FAX ● Caller Identification/Call Waiting/Call ● Forwarding/Call Transfer/Call Hold/3-way Conference ● Line testing according to GR-909
WIFI	●Wi-Fi 6: 802.11a/n/ac/ax 5GHz & 802.11g/b/n/ax 2.4GHz ●Wi-Fi Encryption: WEP-64/WEP-128/ WPA/WPA2/WPA3 ●Support OFDMA, MU-MIMO, Dynamic QoS, 1024-QAM ●Smart Connect for one Wi-Fi name – One SSID for 2.4GHz and 5GHz dual band
L2	802.1D&802.1ad bridge, 802.1p Cos,802.1Q VLAN
L3	IPv4/IPv6, DHCP Client/Server,PPPoE, NAT, DMZ, DDNS
Firewall	Anti-DDOS, Filtering Based on ACL/MAC /URL
Dimension	244mm131mm36mm (L×W×H)
Net weight	0.425Kg
Operating condition	● Operating temp: -10 ~ +55°C ● Operating humidity:5 ~ 95% (non-condensed)
Storing condition	● Storing temp: -40 ~ +70°C ● Storing humidity: 5 ~ 95% (non-condensed)
Power adapter	DC 12V, 2A, external AC-DC power adaptor
Power supply	≤24W
Interface	12.5GE+3GE+1*USB 3.0+Wi-Fi 6 AX3000
Indicators	PON/LOS, WAN, USB, Wi-Fi

Product Name

Product Description

Accessories

ZY-XG-304AX-X26

XGPON PROT +1*2.5GE+3*GE+1*USB3.0+WiFi 6 AX3000

AC-DC power adaptor: DC12V/2A

Color : white optional

1. What is the delivery time for XGPON PROT +1*2.5GE+3*GE+1*USB3.0+WiFi 6 ?

The delivery time may vary depending on the quantity and specific requirements. The standard delivery time is 15-20 working days. Please reach out to our sales team for more information regarding the estimated delivery time.

2. Can the XGPON ONU be customized to meet specific needs?

Yes, we offer customization options for the XGPON ONU based on specific requirements such as logo, interface configuration, default settings, and connector type. Please contact our sales team to discuss your customization needs.

3. What type of technical support is provided for the XGPON ONU?

We provide comprehensive technical support for the XGPON ONU, including product documentation, troubleshooting guides, and remote assistance. Our technical team is available to assist you with any inquiries or issues you may encounter.

4. What shipping methods are available for the XGPON ONU 10G PON DUAL BAND AX3000 ZY-XG-304AX-X26?

We offer various shipping methods for the including air freight, sea freight, and express delivery. You can choose the shipping method based on your preference and urgency. Please contact our sales team for more details on shipping options.
